Torque Sensor for Belt Pulleys

Dieser Sensor hat eine berührungslose und digitale Signalübertragung von Rotor zu Stator, also ohne
Signalverf?lschung und wartungsfrei.
Nominal (rated) torques 50 N.m,
100 N.m, 200 N.m, 500 N.m,
1 kN.m, 2 kN.m, 3 kN.m, 5 kN.m
and 10 kN.m

24-hour national online service:

025-84363968

consult

Introduction
List
Notice

Rated capacity	±50 N?m ~ ±3 kN?m
Safe overload	150 %R.C.
Ultimate overload	300 %R.C.
Rated output	0 V ~ ±10 V0 V ~ ±5 V 4-20mA 5-15kHz 485 CAN
Accuracy of detected value	Digital : ±0.5 %R.O., Analog : ±0.25%R.O.±0.1%R.O. (including linearity, hysteresis and repeatablity.)
Maximum rotation speed	RK-700100NM ~ -300NM : 5 000 rpm RK-700-500NM, -1KNM :4000 rpm RK-700-2KNM, -3KNM : 35 00 rpm
Temp. range, safe	-10 ℃ ~ 70 ℃
Temp. range, compensated	0 ℃ ~ 60 ℃
Temp. effect on zero balance	0.02 %R.O./10 ℃
Temp. effect on output	0.03 %LOAD/10 ℃
Zero shift by rotation	0.5 %R.O.p-p (at WB＝1 kHz)
Mechanical characteristics	100NM	200NM	300NM	500NM	1kNM	2KNM	3KNM
Torsional peculiar pitch (kHz)	5.357	5.778	6.577	6.413	6.274	4.040	4.508
Bending peculiar pitch
Radial direction (kHz)	3.375	3.497	3.763	3.919	4.016	2.151	2.368
Thrust direction (kHz)	3.966	4.065	4.284	4.404	4.988	2.672	2.844
Twist angle at rated capacity (°)	0.015	0.027	0.031	0.037	0.049	0.067	0.082
Accuracy safe bending load (N)	75	150	225	375	750	800	1 000
Accuracy safe thrust load (N)	65	130	195	325	650	3 750	12 000
Class of protection	IP54
Material	Rotor part : Alloy steel, Stator part : Alluminium alloy
